SATURNevo for general purpose

Main pumped products

Water Wastewater Hydrofluoric acid Caustic soda Sodium hypochlorite Nitric acid Sodium chloride Formic acid Acetic acid Phosphoric acid Hydrogen peroxide Seawater Polluted water Pure water Water with impurities Treated water

Composition

V1G | Standard vinyl ester resin FRP

The ideal solution for the major part of corrosive agents containing acids, alkalies, detergents, sea water, brine, etc.

Thermosetting resins, unlike thermoplastic products, are no longer processable after the catalysis process. This chemical property guarantees better mechanical properties, heat and dimensional stability, and longer durability.

Fiberglass makes it possible to design at best the most mechanically stressed parts. It also ensures an excellent chemical resistance of surfaces in contact with pumped fluids.

Request info

CaptchaRefresh Code

  • Long-coupled "ZGS" or close-coupled "ZMS"

  • Compact version "ZCS" for small spaces

  • Capacities up to 1350m3/h

  • Excellent mechanical strength and chemical resistance

  • Performance efficiency superior to 80% guaranteeing high-quality consistent over time

  • Epoxy resin reinforced with fiberglass is free from liquid aggression (corrosion) and therefore does not release particles or substances that can alter the liquid

  • Back pull-out system for long-coupled version (= easy maintenance)

  • ANSI/ASME B73.1 conformity

  • Upon request:  ATEX Zone 2 (II 3G Ex h IIB T4 Gb X) with conductive liner

  • Lightweight thanks to construction materials and ARGAL technology

  • Impeller made of FRP reinforced with carbon fiber for more strength (cavitation issues are reduced to minimum)

  • Adjustable baseplate entirely made of FRP

  • Feet and flanges reinforced

  • 80% customizable with the ARGAL TAILOR-MADE Program

  • ​FRP accessories to empower or adapt the pump to any system

  • Upon request: possibility to choose the color of your pump

Applications

The combination of chemical and mechanical resistance, the lightness and the substantial cost-effectiveness of the solutions proposed make SATURNevo a valid alternative to pumps made of special metal alloys, among which we would like to mention those intended for seawater applications:

  • Aquaculture

  • Desalination

  • Seawater processes

  • Chemical processes

  • Metal and mineral industries

  • Oil and gas

  • Pharmaceutical industry

  • Water and wastewater treatments
