PP+glass

Main pumped products

Mastic Industrial oil Mineral oil Oily varnish AD Blue

Composition

Polypropylene reinforced with fiberglass

It offers high chemical resistance and high mechanical strength. Ideal for corrosive liquids and slightly abrasive. It is not compatible with based-petroleum solvents.

DDE 007

DDE 15

DDE 20

DDE 30

DDE 60

DDE 80

DDE 100

DDE 160

DDE 400

DDE 650



Request info

CaptchaRefresh Code

  • High hydraulic performance up to 715 l/min

  • Optimized air consumption

  • Evolved diaphragm caps

  • Non-icing air valve system

  • Operating sensitivity improved (from 1 bar)

  • Integrated muffler up to model DDE 160

  • Easy maintenance

  • Ideal for shear-sensitive liquids

  • modified PTFE diaphragms inert to chemical agents

  • Diaphragms available in thermoplastic materials (TPE, TPV) and reinforced elastomers (FKM, EPDM, NBR)

  • Dry-running

  • Self-priming

  • Upon request:  FDA conformity with ASTRAevo FOOD version

  • Upon request:  ATEX Zone 2 (II 3G Ex h IIB T4 Gb X | II 3D Ex h IIIB T135°C Db X) and Zone 1 (II 2G Ex h IIB T4 Gb X | II 3D Ex h IIIB T135°C Db X) with conductive body and parts

Standard connections




Upon request: all connection configurations are available for plastic and aluminum versions.

  • AISI 316l versions can be set with the connections up to model DDE 160. Models DDE 400 and DDE 650 have the flanged connections "F-B"

  • It is not possible to set the "F-B" connections and  "V" connection is not recommended for model DDE 020

For further connection configurations, contact us

Applications

  • Chemical production

  • Surface treatment

  • Water and wastewater treatment

  • Aerospace

  • Pulp and paper

  • Automotive

  • Flexographic

  • Pharmaceutical

  • ...
